Home > Products > Electric Forklifts > 4-Wheel Electric Forklifts

4-Wheel Electric Forklifts

1.5–5 Ton Electric Counterbalance Forklifts

HAMAC 4-wheel electric forklifts are electric counterbalance forklifts designed for stable, efficient and low-emission pallet handling in warehouses, factories, logistics centers, loading docks and industrial storage yards. The four-wheel chassis provides strong stability during lifting, traveling and stacking operations, making it suitable for customers who need a versatile electric forklift for both indoor and semi-outdoor material handling.

The 4-wheel electric forklift range can be configured with lead-acid batteries or lithium-ion batteries, depending on the working schedule, charging conditions and maintenance requirements. Customers can also select different mast heights, fork lengths, tire types, side shifters, fork positioners, safety lights, cabin options and other attachments to match their pallet dimensions, rack height, floor condition and handling tasks.

Rated Capacity:1500–5000 kg

Battery Options:Lead-acid Battery or Lithium-ion Battery

Lift Height:Up to 6500 mm, depending on mast configuration

4 wheel electric-Technical Specifications Overview

Get a Quote → Ask for Details →

HAMAC 4-wheel electric forklifts are available in capacities from 1.5 tons to 5 tons. The 1.5T, 1.8T and 2T models are suitable for general warehouse handling, light manufacturing, retail distribution and spare-parts storage. The 2.5T, 3T and 3.5T models are the main choices for factories, loading docks, building material warehouses, beverage distribution and medium-duty logistics operations.

For customers handling heavier pallets, molds, machinery parts, paper rolls, construction materials or high-volume goods, 4T and 5T electric forklifts can provide higher capacity electric material handling solutions. Before choosing a 4-wheel electric forklift, HAMAC recommends confirming the rated load, load center, lift height, pallet size, aisle width, ground condition, daily working hours, battery type, available charger power and required forklift attachments.

Product Advantages

01 Zero-Emission Operation

Electric forklifts produce no exhaust emissions during operation, making them suitable for warehouses, factories, food and beverage facilities, distribution centers, packaging plants and other indoor material handling environments. They help customers maintain cleaner working areas while supporting daily pallet transport, loading and stacking tasks.

02 Low Noise for Indoor Work

The electric drive system operates with lower noise than conventional internal combustion forklifts. This improves operator comfort and is particularly valuable in enclosed warehouses, production workshops, retail distribution facilities and locations where noise control is important.

03 Flexible Battery Solutions

HAMAC electric forklifts can be configured with conventional lead-acid batteries or lithium-ion battery systems. Lead-acid battery options are suitable for standard operations and budget-focused projects, while lithium-ion forklifts support fast charging and opportunity charging for high-frequency and multi-shift material handling applications.

04 Compact and Maneuverable Design

Electric forklifts are available in both 3-wheel and 4-wheel configurations. Three-wheel electric forklifts offer a small turning radius for narrow aisles and compact warehouses, while four-wheel electric forklifts provide stable handling for factories, loading docks and general indoor-outdoor operations on level ground.

05 High Visibility and Precise Control

A high-visibility mast, ergonomic operator compartment and responsive electric control system help operators position forks accurately and handle pallets with confidence. This improves efficiency during truck loading, rack storage, production-line supply and repetitive warehouse handling tasks.

06 Configurable for Different Applications

HAMAC electric forklifts can be equipped with different mast heights, duplex or triplex full free lift masts, side shifters, fork positioners, fork extensions, solid tires, non-marking tires, safety lights, cameras and other attachments. This allows customers to configure the forklift for pallet dimensions, rack heights, aisle widths, operating hours and specific material handling requirements.

Compatible Attachments

Rallet fork

Bucket

Crane Arm

Mixed barrel

Bale Fork

Snow Blower

Grapple Bucket

Mixed Bucket

Road Sweeper

Mixed barrel

Crass Cutter

Application Scenarios

Construction Sites

Agriculture & Farming

Industrial Logistics

Municipal Works

Mining & Energy

Technical Specifications

Item	Unit	FE15	FE18	FE20	FE25	FE30	FE35	FE40	FE50
General
Model	-	FE15	FE18	FE20	FE25	FE30	FE35	FE40	FE50
Power Type	-	Battery	Battery	Battery	Battery	Battery	Battery	Battery	Battery
Operator Type	-	Seated	Seated	Seated	Seated	Seated	Seated	Seated	Seated
Rated Capacity	kg	1500	1800	2000	2500	3000	3500	4000	5000
Load Center	mm	500	500	500	500	500	500	500	500
Wheelbase	mm	1250	1250	1450	1450	1700	1700	2000	2000
Tire Type	-	Solid / Pneumatic Optional	Solid / Pneumatic Optional	Solid / Pneumatic Optional	Solid / Pneumatic Optional	Solid / Pneumatic Optional	Solid / Pneumatic Optional	Solid / Pneumatic Optional	Solid / Pneumatic Optional
Number of Wheels, Front / Rear	-	2 / 2	2 / 2	2 / 2	2 / 2	2 / 2	2 / 2	2 / 2	2 / 2
Mast and Forks
Standard Lift Height	mm	3000	3000	3000	3000	3000	3000	3000	3000
Optional Lift Height	mm	3000-6000	3000-6000	3000-6500	3000-6500	3000-6500	3000-6500	3000-7000	3000-7000
Mast Type	-	Duplex / Triplex	Duplex / Triplex	Duplex / Triplex	Duplex / Triplex	Duplex / Triplex	Duplex / Triplex	Duplex / Triplex	Duplex / Triplex
Free Lift	mm	Optional	Optional	Optional	Optional	Optional	Optional	Optional	Optional
Mast Tilt Angle, Forward / Backward	deg	5 / 7	5 / 7	5 / 7	5 / 7	5 / 7	5 / 7	5 / 7	5 / 7
Fork Dimensions, L × W × T	mm	920 × 100 × 35	920 × 100 × 35	1070 × 100 × 40	1070 × 122 × 40	1070 × 122 × 45	1070 × 122 × 45	1220 × 150 × 50	1220 × 150 × 50
Fork Carriage Class	-	IIA	IIA	IIA	IIA	IIIA	IIIA	IIIA	IIIA
Dimensions
Overall Length to Fork Face	mm	2050	2050	2240	2240	2500	2500	2900	3000
Overall Width	mm	1080	1080	1150	1150	1250	1250	1400	1450
Overhead Guard Height	mm	2040	2040	2100	2100	2150	2150	2250	2300
Ground Clearance under Mast	mm	90	90	100	100	110	110	120	120
Min. Outside Turning Radius	mm	1800	1800	1980	1980	2250	2300	2550	2700
Performance
Travel Speed, Laden / Unladen	km/h	12 / 13	12 / 13	13 / 14	13 / 14	14 / 15	14 / 15	14 / 15	14 / 15
Lifting Speed, Laden / Unladen	m/s	0.28 / 0.45	0.28 / 0.45	0.30 / 0.48	0.30 / 0.48	0.32 / 0.50	0.32 / 0.50	0.30 / 0.48	0.30 / 0.48
Lowering Speed, Laden / Unladen	m/s	0.45 / 0.40	0.45 / 0.40	0.50 / 0.45	0.50 / 0.45	0.50 / 0.45	0.50 / 0.45	0.50 / 0.45	0.50 / 0.45
Max. Gradeability, Laden / Unladen	%	12 / 15	12 / 15	12 / 15	12 / 15	12 / 15	12 / 15	10 / 12	10 / 12
Drive System
Drive Motor Type	-	AC Drive Motor	AC Drive Motor	Dual AC Drive Motor	Dual AC Drive Motor	Dual AC Drive Motor	Dual AC Drive Motor	Dual AC Drive Motor	Dual AC Drive Motor
Drive Motor Power	kW	8	8	10	10	2 × 8	2 × 8	2 × 10	2 × 12
Lift Motor Power	kW	10	10	12	12	15	15	20	25
Controller	-	Curtis / ZAPI Optional	Curtis / ZAPI Optional	Curtis / ZAPI Optional	Curtis / ZAPI Optional	Curtis / ZAPI Optional	Curtis / ZAPI Optional	Curtis / ZAPI Optional	Curtis / ZAPI Optional
Steering Type	-	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering
Battery and Charger
Battery Type	-	Lead-acid / Lithium-ion Optional	Lead-acid / Lithium-ion Optional	Lead-acid / Lithium-ion Optional	Lead-acid / Lithium-ion Optional	Lead-acid / Lithium-ion Optional	Lead-acid / Lithium-ion Optional	Lithium-ion / Lead-acid Optional	Lithium-ion / Lead-acid Optional
Battery Voltage	V	48	48	48	48	80	80	80	80
Battery Capacity	Ah	400-500	400-500	500-600	500-600	600-700	600-700	700-900	800-1000
Charger Type	-	External / On-board Optional	External / On-board Optional	External / On-board Optional	External / On-board Optional	External / On-board Optional	External / On-board Optional	External / On-board Optional	External / On-board Optional
Battery Replacement Method	-	Side Extraction Optional	Side Extraction Optional	Side Extraction Optional	Side Extraction Optional	Side Extraction Optional	Side Extraction Optional	Side Extraction Optional	Side Extraction Optional
Optional Configurations
Available Options	-	Lead-acid Battery, Lithium-ion Battery, Side Shifter, Fork Positioner, Fork Extensions, Duplex Mast, Triplex Full Free Lift Mast, Solid Tires, Pneumatic Tires, Non-marking Tires, On-board Charger, Blue Safety Light, Red Zone Warning Light, Rear Working Light, Camera System, Cold Storage Package, Full Cabin and Fleet Management System

Product Overview Product Advantages Compatible Attachments Application Scenarios Technical Specifications

Free Consultation →

Common FAQs

What is a 4-wheel electric forklift? −

A 4-wheel electric forklift is a battery-powered counterbalance forklift with two front wheels and two rear wheels. It is designed for stable pallet handling in warehouses, factories, logistics centers, loading docks, and industrial facilities. Compared with a 3-wheel electric forklift, a 4-wheel electric forklift generally provides stronger chassis stability and is suitable for a wider range of capacities and working conditions.

What capacity range is available for HAMAC 4-wheel electric forklifts? +

HAMAC 4-wheel electric forklifts are available from 1.5 tons to 5 tons. The main models include FE15, FE18, FE20, FE25, FE30, FE35, FE40, and FE50. The 2.5 ton electric forklift, 3 ton electric forklift, and 3.5 ton electric forklift are commonly selected for general factory, warehouse, and logistics operations.

What is the difference between a 3-wheel and a 4-wheel electric forklift? +

A 3-wheel electric forklift is usually selected for narrow aisle warehouses because it has a smaller turning radius. A 4-wheel electric forklift provides better stability, especially for heavier pallets, longer travel distances, outdoor loading areas, and mixed indoor-outdoor applications. HAMAC can recommend the right electric forklift according to your aisle width, pallet weight, lift height, and floor condition.

Can a 4-wheel electric forklift be used outdoors? +

Yes. A 4-wheel electric forklift can be used in outdoor loading areas, factory yards, and covered logistics spaces when the ground is relatively flat and dry. For outdoor work, customers can select pneumatic tires, higher ground clearance, weather protection, a full cabin, and suitable battery capacity. For muddy, unpaved, or rough construction sites, a diesel rough terrain forklift is usually more suitable.

Does HAMAC offer lithium-ion 4-wheel electric forklifts? +

Yes. HAMAC can provide lithium-ion battery options for selected 4-wheel electric forklift models. A lithium-ion electric forklift supports fast charging and opportunity charging, making it suitable for high-frequency operations, multi-shift warehouse work, logistics centers, and customers who want to reduce battery maintenance requirements.

What lift height is available for a 4-wheel electric forklift? +

HAMAC 4-wheel electric forklifts can be configured with duplex and triplex masts. Typical lift heights range from 3000 mm to 7000 mm, depending on the forklift model, mast type, battery configuration, and residual capacity requirement. Customers should provide their rack height, building clearance, and pallet size before selecting a mast.

Can a 4-wheel electric forklift work in a warehouse with high racks? +

Yes. A 4-wheel electric counterbalance forklift can handle medium-height and high-rack warehouse work when configured with the correct triplex full free lift mast. Before selecting the forklift, confirm the required lift height, lowered mast height, extended mast height, aisle width, pallet dimensions, and residual capacity at the maximum lift height.

Which battery is better for a 4-wheel electric forklift: lead-acid or lithium-ion? +

Lead-acid batteries are suitable for customers with standard single-shift working schedules, planned charging time, and lower initial investment requirements. Lithium-ion batteries are more suitable for high-utilization operations because they support faster charging, opportunity charging, and lower daily battery maintenance. HAMAC can recommend a battery solution based on your working hours, shifts, available charging power, and budget.

What attachments are available for HAMAC 4-wheel electric forklifts? +

HAMAC 4-wheel electric forklifts can be equipped with side shifters, fork positioners, fork extensions, carton clamps, bale clamps, paper roll clamps, drum handlers, and other forklift attachments. The attachment weight, load center, and residual capacity must be confirmed before purchase, especially for 2.5 ton, 3 ton, and 3.5 ton electric forklifts handling non-standard loads.

What information should I provide before buying a 4-wheel electric forklift? +

Please provide the required load capacity, load center, maximum lift height, pallet size, aisle width, working environment, floor condition, daily operating hours, battery preference, available charging voltage, attachment requirements, quantity, and destination country. HAMAC can then recommend a suitable 4-wheel electric forklift model with the correct battery, mast, tire, and attachment configuration.
